◆Table work surface size (mm): 605 x 600
◆Table travel distance (mm): 800 x 652
◆Distance from table top to grinding wheel bottom (standard grinding wheel) (mm): -2.5 to 497.5
◆Standard chuck dimensions (mm): 600 x 600 x 100
◆Maximum table load capacity (including accessories) (kg): 1500
◆Table left/right (X-axis)
◆Left/right feed speed (average) (m/min): 3 to 25
◆Column Forward and backward feed (Z-axis)
◆Manual forward and backward feed (feed amount per rotation of hand handle) (mm): 0.1/1.0/5.0
◆Manual forward and backward feed (feed amount per division of hand handle) (mm): 0.001/0.01/0.05
◆Automatic forward and backward feed (intermittent feed) (mm): 0.5 to 20
◆Automatic forward and backward feed (continuous feed speed) (mm/min): 0.1 to 2000
◆Grinding wheel head up and down feed (Y-axis)
◆Manual cutting depth feed (feed amount per rotation of hand handle) ) (mm): 0.01/0.1/1.0
◆Manual cutting feed (feed amount per hand handle division) (mm): 0.0001/0.001/0.01
◆Automatic cutting feed amount (rough grinding) (mm): 0.0001 to 0.03
◆Automatic cutting feed amount (fine grinding) (mm): 0.0001 to 0.01
◆Number of spark-outs (time): 0 to 10
◆Up/down speed feed rate (mm/min): 0 to 1000
◆Grinding wheel
◆Outer diameter × Width x Inner Diameter (mm): Φ400 x 50 x Φ127
◆Rotation Speed ​​(with stepless speed control for grinding wheel shaft) (min-1): 200-2500
◆Motor
◆Grinding Wheel Shaft (kW): 7.5
◆Hydraulic Pump (kW): 3.7
◆Up/Down Feed (kW): 1.5
◆Forward/Backward Feed (kW): 0.75
◆Required Power (kVA): 20
◆Net Weight (kg): 6300

✤In case of discrepancies between specifications and the actual product, the actual product will take precedence.
