Specification
◆ Machining range of workpieces: 4000 x 800 x 800 mm
◆ Table work surface: 4050 x 800
◆ Standard chuck dimensions: 4000 x 800 x 100 mm
◆ Loading weight: 3728kg
◆ T-groove width x number: 20 mm x 3
◆ XYZ: 4250 x 800 x 860
◆ Whetstone: Outer diameter x Width x Inner diameter / φ510 x 100 x φ203.2
◆ Grindstone rotation speed: 1000 / 1200rpm (50 / 60Hz)
◆ Machine dimensions: W11000 x D4500 x H3780mm
◆ Weight: 30000kg
Photo (16)
