Specification
[There is a video 📹. Please see below! ]
◆MAZATROL MATRIX
◆Table: 1300×550
◆XYZ: 1050×510×510
◆Table maximum loading weight: 1200kg
◆Spindle taper: 7/24 taper No.40
◆ATC30
◆MAS BT40
◆Coolant tank capacity: 250L
◆Machine dimensions: W2880 x D2835 x H2843mm
◆Mass: 6,900kg
※No touch sensor, touch probe, tool length measurement
※No automatic work measurement
※No chip conveyor
※With spindle through coolant
