Specification
◆ Swing on the bed: 1250mm
◆ Swing on the carriage: 910mm
◆ Swing on the cut-off: 1660mm
◆ Maximum distance between hearts: 5100mm
◆ Bed width: 750mm
◆ Bed length: 7520mm
◆ Spindle speed: 6-590rpm
◆ Spindle taper: AST # .350
◆ Spindle hole diameter: 80mm
◆ Horizontal feed amount: 800mm
◆ Tool post travel: 330mm
◆ Floor area: 7977mm × 2310mm
◆ Weight: 15500kg
