Specification
◆OSP-U100L
◆KITAGAWA B210 chuck
◆ Swing on the bed: φ530
◆ Swing on the carriage: φ530
◆ Swing of horizontal feed base: φ420
◆ Between centers: 1020
◆ Maximum machining diameter: φ370 × 1000
◆ Spindle diameter: φ100mm
◆ Spindle through hole: φ62
◆ 45 ～ 4500min-1
◆ XZ: 260 × 520
◆ V12
◆ Machine size: 3310 × D1895 × H1925mm
◆ Weight: 5900kg
※Chip conveyor
