surface grinder (PSG-64DX)
k-smk.co.jp/en/machines/20601048/
| 分類 | Surface grinding machine |
|---|---|
| メーカー | OKAMOTO |
| 保管場所 | Head office. Machine Plaza |
| 型式 | PSG-64DX |
| 年式 | 1990 |
| 管理番号 | 20601048 |
◆Size of table work surface: 605 x 400mm
◆Table movement amount: 750 x 440mm
◆Dimensions of standard chuck that can be installed: 600 x 400 x 85
◆Workpiece allowable mass (including chuck): 420kg
◆T groove width x number: 17 x 3
◆Left and right feed speed (average) 0.3 to 25m/min
◆Left and right handle feed amount per revolution: 47mm
◆Required power supply: 3-phase 200V.50/60Hz 3-phase 220V.60Hz
◆Power capacity: 10kVA
◆Occupied volume (frontage x depth x height): 2737 x 2203 x 1809
◆Machine mass: 3000kg
✤If there is a discrepancy between the specifications and the actual product, priority will be given to the actual product.
