Electric servo injection molding machine (TR75EHV)
k-smk.co.jp/en/machines/4099y430/
| 分類 | Other Machines |
|---|---|
| メーカー | Sodick |
| 保管場所 | Each sites |
| 型式 | TR75EHV |
| 年式 | 2014（未使用機） |
| 管理番号 | 4099Y430 |
❄Unused machine made in 2015! ❄
◆ Mold opening and closing method: Electric servo ball screw
◆ Clamping method: Template plate descending direct pressure type
◆ Maximum clamping force: 735kN
◆ Tie bar spacing: 450 × 450mm
◆ Platen dimensions: 670 × 670
◆ Delight: 550
◆ Minimum mold thickness: 250
[Plasticizing injection device]
◆ Screw diameter: 28
◆ Maximum injection pressure: 252MPa
◆ Plunger stroke: 135
◆ Maximum screw rotation speed: 280
◆ Nozzle pressing force: 17.6kN
◆ Hydraulic pump motor capacity: 7.5kW
◆ Hydraulic circuit pressure: MAX.18.5MPa
◆ Tank capacity: 130L
◆ AC servo motor capacity: 5.6kW
◆ Dimensions: W2570 × D1812 × H3752mm
◆ Mass: 4800kg
